Stall build

We have a lean to that is legit, the size of a barn, and I would like to section off a part of the back to create an insulated stall for the colder winter months. I googled stall builds and I see these extravagant looking stalls that I would feel comfortable sleeping in, and I have no idea where to even start. Where does one find the metal bars that are used in these stalls? How big is too big, or is it possible to be too big? The lean to has a dirt ground, I've seen this before in some barn stalls, but I'm not sure if a rubber mat would be more appreciated by the horse? Is there a certain type of wood that is better than another when it comes to a stall build? We want to do this right!
rkn is offline
Sponsored Links
Advertisement

post #2 of 11 Old 08-04-2013, 08:42 AM
Weanling

Join Date: Nov 2009
Posts: 302
• Horses: 0
This is what we did. When we moved into this farm there was a large run in attached to a barn type structure and that was it. We built 3 10x10 (they seem a little larger though) stalls into the back of the run in shed. They are basice stalls made of 2x6 pine and pressure treated posts. They have dutch doors on the front and a wire mesh for now on the windows. My mare has already ripped the mesh apart so maybe at some point we'll replace it for rebarb. But I rarely shut the top doors anyway so it's not that much of a big deal.

Here are some pictures so you can see them. The walls between are called summer walls around here. It was cheaper to have them spaced 1.5" apart and this way the horses can see each other :)




star16, MGTS, KigerQueen and 1 others like this.
Nickers2002 is offline
post #3 of 11 Old 08-04-2013, 08:46 AM
Weanling

Join Date: Jun 2011
Posts: 706
• Horses: 17
looks awesome!
GhostwindAppaloosa is offline
post #4 of 11 Old 08-05-2013, 12:22 PM Thread Starter
rkn
Foal

Join Date: Aug 2013
Location: MTL, QC
Posts: 26
• Horses: 1
very nice! It definitely gives me something to base my design off of! Thanks! :)
KigerQueen likes this.
rkn is offline
post #5 of 11 Old 08-05-2013, 12:54 PM
Trained

Join Date: Aug 2013
Location: Colorado
Posts: 6,970
• Horses: 1
Very cute!
Zexious is offline
post #6 of 11 Old 08-05-2013, 01:05 PM
Foal

Join Date: Jan 2011
Location: NC
Posts: 187
• Horses: 1
I hope you don't mind, but I liked your stalls so much that I pinned them to my "someday" barn idea board on pinterest. Great simple "real" stalls that I could easily have help making. Do let me know if you would prefer that I remove the link?
commonfish is offline
post #7 of 11 Old 08-05-2013, 09:29 PM
Weanling

Join Date: Nov 2009
Posts: 302
• Horses: 0
That's fine commonfish :)

I'm glad you all like the stalls. It was the easiest ones we could do on a budget lol.
Nickers2002 is offline
post #8 of 11 Old 08-06-2013, 11:32 AM
Trained

Join Date: Jan 2011
Location: Palmyra, Wisconsin
Posts: 5,654
• Horses: 4
For bars, buy conduit & cut it to size.
natisha is online now
post #9 of 11 Old 08-06-2013, 02:39 PM
Foal

Join Date: Aug 2012
Location: Wisconsin
Posts: 203
• Horses: 2
Thank you for posting this, as I've been considering something similar for awhile now!
star16 is offline
post #10 of 11 Old 10-04-2013, 11:23 AM
Started

Join Date: Oct 2013
Posts: 2,025
• Horses: 0
I know this thread is a few months old...I am new to this site.
I just wanted to say...

Beautiful barn..

Instead of a conduit idea for bars, you can also use thick white plastic pipe(plumbing section of Lowes/HomeDepot) built with a slip frame so you can actually slide up a section to get to the grain bucket not having to go in the stall.
For those of you with Tractor Supply Stores local...they make "livestock panels"...with various size openings...2"x4", 4"x 4", and some with graduated sizes of larger on top to smaller on bottom. They are very strong in nature, 16 feet long and height vary from 36" - 48". Price is anywhere from $18.00 - $75.00 per panel.
I have seen the 4"x4" opening panels($18.00) used for horse stall wall tops for ventilation and "seeing but not touching" of another with great success.
Just a thought...
horselovinguy is offline
